Steel Target Care Guide

Keep your targets in great shape with these simple tips.

General Use Tips

  • Use the Right Ammo:
    • Avoid steel-core, armor-piercing, or steel-jacketed rounds to prevent damage.
    • Stick to lead-core bullets for the best results.
  • Keep Impact Within Limits:
    • For AR450-AR500 steel, ensure bullet velocity is under 3,000 fps at the target.
    • Mild steel is only for .22LR—larger calibers will cause damage.
  • Set Targets at Proper Angles:
    • Slightly angle targets downward to deflect splatter and reduce wear.

Maintenance & Care

  • Clean After Shooting:
    • Wipe off debris with a soft brush or cloth.
    • Use a mild solvent for heavy residue. Avoid harsh chemicals.
  • Remove Surface Rust:
    • Surface rust will naturally be blown off during shooting, but you can wipe or sand it lightly if needed.
  • Lubricate Moving Parts:
    • Apply WD-40 or a similar lubricant to target mechanisms, hinges, and guide tracks to keep them running smoothly.
  • Inspect for Damage:
    • Regularly check for cracks, dents, or deep pitting. Replace any compromised targets for safety and performance.
    • guide tracks for our drop tree may need filing to maintain a smooth guiding surface for the target plate to reduce hang-ups.
  • Check Timber Posts:
    • Inspect wooden posts for excessive wear from the environment or shrapnel. Replace them as necessary to ensure stability.
  • Protect From Rust:
    • Store targets in a dry area.
    • For mild steel, apply a light coat of oil or WD-40 to prevent corrosion.

Prolong Target Life

  • Rotate Impact Zones: Move targets or adjust setups to spread out wear.
  • Use Reactive Systems: Swinging or resetting targets absorb more energy and last longer.
  • Repaint Regularly:
    • Use spray paint for better visibility and surface protection.
    • Remove old paint build-up as needed.

Edge Chipping & Target Wear: Causes & Impact

Why It Happens:

  • Normal for AR500 targets hit by bullets over 2,000 fps.
  • Harder steel + higher velocity = increased chipping.
  • Edges lack support.

Is It Dangerous?

  • No. Edge chipping doesn’t create craters or unsafe lead redirection towards the shooter. Bullets over 2,000 fps tend to vaporize on impact. (depending on various factor)

What You Can Do:

  •  High Velocity: Unavoidable over 2,000 fps. (lower the velocity or increase target distance)
  •  Target Size: Larger gongs (e.g., 20") get fewer edge hits.
  •  Longevity: Flip targets if chipping worsens. (Tends to not reach the other side)
  •  Pitting & Warping: Caused by heat, not thickness. Thicker targets may pit more as they absorb more energy.
  •  Mounting: Angling targets downward improves safety and reduces heat build-up.
  •  Excessive Wear: If pocking, pitting, or warping becomes excessive, retire the target or use no closer than 150 meters.
